Jth90 Hollow Shaft 3 Way Bevel Gearbox 1: 1 Ratio Small Gearboxes Hollow Shafts

Product Description

JTH90 hollow shaft 3 way bevel gearbox 1:1 ratio small gearboxes hollow shafts features:
1. Maximum allowable torque 43.29N.m, Maximum allowable power 6kw, Maximum allowable speed 1500rpm.
2. Standard solid input shaft diameter 18mm, customized smaller or larger sizes input shafts.
3. Maximum allowable hollow shaft diameter 16mm, customized smaller sizes hollow shafts.
4. Cubic housing, 90mm square box, with all-round tapped holes for universal mounting, 6 possible universal mounting positions, can be easily mounted in any direction.
5. Standard bevel gear ratios 1:1 and 2:1, custom made 1.5:1, 3:1, 4:1 and 5:1 reduction ratios.
6. Drive shafts arrangements available 2-way, 3-way, and 4-way.
7. Drive shafts can be rotated in both clockwise and counter-clockwise rotation direction.

8. Quiet low noise, low backlash, low running temperature.

JTH90 hollow shaft 3 way bevel gearbox 1:1 ratio small gearboxes hollow shafts Dimensions
1. Standard solid input shaft diameter 18mm, customized smaller or larger sizes input shafts.
2. Maximum allowable hollow shaft diameter 16mm, customized smaller sizes hollow shafts.
